Introduce

Power Options:

• USB-C Type or PoE 802.3af for powering the HMG.

Connectivity:

• Supports Zigbee over LAN, USB, WiFi.

Main Components:

• Uses ESP32, LAN8720, CH340C chips.
• Incorporates TI CC2652P2 with a +20db amplifier. New hardware revisions (v0.2+) use TI CC2652P7.

Device Capabilities:

• Supports up to 300 Zigbee devices.
• Operates in both Coordinator and Router modes.
• Equipped with 3 LEDs for user feedback:
• Blue: Power Indicator
• Red: USB/LAN Working Mode
• White: Z2M Connection

User Features:

• DIY Pinouts available.
• Easily change working modes with a button press:
• Single Press: Toggle between USB/LAN Mode
• Hold (2-4 sec): Control LED's ON/OFF
• Hold (4-8 sec): Activate Flashing Mode
• Hold (10+ sec): Reset device on power-up

Additional Features:

• Update ESP32 & CC2652P firmware via LAN, Internet, USB.
• Security authentication.
• Open Source Firmware.
• Compact design: 73x72x27mm.
• Plug & Play, pre-flashed firmware.
